Gourmet Ice: A top class must

Small and medium production

AC series

AC 46

Condensing system: Air cooled, Water cooled
Max daily production: 24,5 kg
(referred to the standard model)
  • ACM 46 AS 230/50/1
Max bin capacity: 9 kg
Dimensions without legs: W 386 mm D 600 mm H 643 mm
Dimensions with legs: W 386 mm D 600 mm H 645 mm

AC 47

Condensing system: Air cooled
Max daily production: 25 kg
(referred to the standard model)
  • ACM 47 AS 230/50/1
Max bin capacity: 9 kg
Dimensions without legs: W 386 mm D 600 mm H 643 mm
Dimensions with legs: W 386 mm D 600 mm H 645 mm

AC 56

Condensing system: Air cooled, Water cooled
Max daily production: 31,5 kg
(referred to the standard model)
  • ACM 56 AS 230/50/1
Max bin capacity: 12 kg
Dimensions without legs: W 386 mm D 600 mm H 693 mm
Dimensions with legs: W 386 mm D 600 mm H 695 mm

AC 57

Condensing system: Air cooled
Max daily production: 33 kg
(referred to the standard model)
  • ACM 57 AS 230/50/1
Max bin capacity: 12 kg
Dimensions without legs: W 386 mm D 600 mm H 693 mm
Dimensions with legs: W 386 mm D 600 mm H 695 mm

AC 86

Condensing system: Air cooled, Water cooled
Max daily production: 38 kg
(referred to the standard model)
  • ACM 86 AS 230/50/1
Max bin capacity: 19 kg
Dimensions without legs: W 531 mm D 600 mm H 785 mm
Dimensions with legs: W 531 mm D 600 mm H 875 mm

AC 87

Condensing system: Air cooled
Max daily production: 45 kg
(referred to the standard model)
  • ACM 87 AS 230/50/1
Max bin capacity: 19 kg
Dimensions without legs: W 531 mm D 600 mm H 785 mm
Dimensions with legs: W 531 mm D 600 mm H 875 mm

AC 106

Condensing system: Air cooled, Water cooled
Max daily production: 50 kg
(referred to the standard model)
  • ACM 106 AS 230/50/1
Max bin capacity: 23 kg
Dimensions without legs: W 531 mm D 600 mm H 840 mm
Dimensions with legs: W 531 mm D 600 mm H 930 mm

AC 107

Condensing system: Air cooled
Max daily production: 53 kg
(referred to the standard model)
  • ACM 107 AS 230/50/1
Max bin capacity: 23 kg
Dimensions without legs: W 531 mm D 600 mm H 840 mm
Dimensions with legs: W 531 mm D 600 mm H 930 mm

AC 126

Condensing system: Air cooled, Water cooled
Max daily production: 70 kg
(referred to the standard model)
  • ACM 126 AS 230/50/1
Max bin capacity: 34 kg
Dimensions without legs: W 680 mm D 600 mm H 920 mm
Dimensions with legs: W 680 mm D 600 mm H 1009 mm

AC 127

Condensing system: Air cooled
Max daily production: 75 kg
(referred to the standard model)
  • ACM 127 AS 230/50/1
Max bin capacity: 34 kg
Dimensions without legs: W 680 mm D 600 mm H 920 mm
Dimensions with legs: W 680 mm D 600 mm H 1009 mm

AC 176

Condensing system: Air cooled, Water cooled
Max daily production: 85 kg
(referred to the standard model)
  • ACM 176 AS 230/50/1
Max bin capacity: 41 kg
Dimensions without legs: W 680 mm D 600 mm H 990 mm
Dimensions with legs: W 680 mm D 600 mm H 1079 mm

AC 177

Condensing system: Air cooled
Max daily production: 85 kg
(referred to the standard model)
  • ACM 177 AS 230/50/1
Max bin capacity: 41 kg
Dimensions without legs: W 680 mm D 600 mm H 990 mm
Dimensions with legs: W 680 mm D 600 mm H 1079 mm

AC 206

Condensing system: Air cooled, Water cooled
Max daily production: 130 kg
(referred to the standard model)
  • ACM 206 AS 230/50/1
Max bin capacity: 50 kg
Dimensions without legs: W 1250 mm D 622 mm H 779 mm
Dimensions with legs: W 1250 mm D 622 mm H 859 mm

AC 206 ICE SHOT

Condensing system: Air cooled, Water cooled
Max daily production: 95 kg
(referred to the standard model)
  • ACX 206 AS I-SHOT 230/50/1
Max bin capacity: 50 kg
Dimensions without legs: W 1250 mm D 620 mm H 779 mm
Dimensions with legs: W 1250 mm D 620 mm H 859 mm

AC 226

Condensing system: Air cooled, Water cooled
Max daily production: 145 kg
(referred to the standard model)
  • ACM 226 AS 230/50/1
Max bin capacity: 70 kg
Dimensions without legs: W 1078 mm D 715 mm H 1004 mm
Dimensions with legs: W 1078 mm D 715 mm H 1082 mm

ACM 25

Condensing system: Air cooled
Max daily production: 10 kg
(referred to the standard model)
  • ACM 25 AE 230/50/1
Max bin capacity: 3 kg
Dimensions without legs: W 380 mm D 388 mm H 640 mm
Dimensions with legs: W 380 mm D 388 mm H 640 mm

EC series

EC 46

Condensing system: Air cooled, Water cooled
Max daily production: 24,5 kg
(referred to the standard model)
  • ECM 46 AS 230/50/1
Max bin capacity: 9 kg
Dimensions without legs: W 386 mm D 600 mm H 643 mm
Dimensions with legs: W 386 mm D 600 mm H 645 mm

EC 47

Condensing system: Air cooled
Max daily production: 25 kg
(referred to the standard model)
  • ECM 47 AS 230/50/1
Max bin capacity: 9 kg
Dimensions without legs: W 386 mm D 600 mm H 643 mm
Dimensions with legs: W 386 mm D 600 mm H 645 mm

EC 56

Condensing system: Air cooled, Water cooled
Max daily production: 31,5 kg
(referred to the standard model)
  • ECM 56 AS 230/50/1
Max bin capacity: 12 kg
Dimensions without legs: W 386 mm D 600 mm H 693 mm
Dimensions with legs: W 386 mm D 600 mm H 695 mm

EC 57

Condensing system: Air cooled
Max daily production: 33 kg
(referred to the standard model)
  • ECM 57 AS 230/50/1
Max bin capacity: 12 kg
Dimensions without legs: W 386 mm D 600 mm H 693 mm
Dimensions with legs: W 386 mm D 600 mm H 695 mm

EC 86

Condensing system: Air cooled, Water cooled
Max daily production: 38 kg
(referred to the standard model)
  • ECM 86 AS 230/50/1
Max bin capacity: 19 kg
Dimensions without legs: W 531 mm D 600 mm H 785 mm
Dimensions with legs: W 531 mm D 600 mm H 825 mm

EC 87

Condensing system: Air cooled
Max daily production: 45 kg
(referred to the standard model)
  • ECM 87 AS 230/50/1
Max bin capacity: 19 kg
Dimensions without legs: W 531 mm D 600 mm H 785 mm
Dimensions with legs: W 531 mm D 600 mm H 825 mm

EC 106

Condensing system: Air cooled, Water cooled
Max daily production: 50 kg
(referred to the standard model)
  • ECM 106 AS 230/50
Max bin capacity: 23 kg
Dimensions without legs: W 531 mm D 600 mm H 840 mm
Dimensions with legs: W 531 mm D 600 mm H 930 mm

EC 107

Condensing system: Air cooled
Max daily production: 53 kg
(referred to the standard model)
  • ECM 107 AS 230/50/1
Max bin capacity: 23 kg
Dimensions without legs: W 531 mm D 600 mm H 840 mm
Dimensions with legs: W 531 mm D 600 mm H 930 mm

EC 126

Condensing system: Air cooled, Water cooled
Max daily production: 70 kg
(referred to the standard model)
  • ECM 126 AS 230/50
Max bin capacity: 34 kg
Dimensions without legs: W 680 mm D 600 mm H 920 mm
Dimensions with legs: W 680 mm D 600 mm H 1010 mm

EC 127

Condensing system: Air cooled
Max daily production: 75 kg
(referred to the standard model)
  • ECM 127 AS 230/50/1
Max bin capacity: 34 kg
Dimensions without legs: W 680 mm D 600 mm H 920 mm
Dimensions with legs: W 680 mm D 600 mm H 1010 mm

EC 176

Condensing system: Air cooled, Water cooled
Max daily production: 85 kg
(referred to the standard model)
  • ECM 176 AS 230/50
Max bin capacity: 41 kg
Dimensions without legs: W 680 mm D 600 mm H 990 mm
Dimensions with legs: W 680 mm D 600 mm H 1080 mm

EC 177

Condensing system: Air cooled
Max daily production: 84 kg
(referred to the standard model)
  • ECM 177 AS PROP. 230/50/1
Max bin capacity: 48 kg
Dimensions without legs: W 680 mm D 600 mm H 990 mm
Dimensions with legs: W 680 mm D 600 mm H 1079 mm

EC 206

Condensing system: Air cooled, Water cooled
Max daily production: 130 kg
(referred to the standard model)
  • ECM 206 AS 230/50
Max bin capacity: 50 kg
Dimensions without legs: W 1250 mm D 622 mm H 779 mm
Dimensions with legs: W 1250 mm D 622 mm H 809 mm

EC 206 ICE SHOT

Condensing system: Air cooled
Max daily production: 95 kg
(referred to the standard model)
  • EC 206 AS ICE SHOT 230/50/1
Max bin capacity: 50 kg
Dimensions without legs: W 1250 mm D 620 mm H 779 mm
Dimensions with legs: W 1250 mm D 620 mm H 822 mm

EC 226

Condensing system: Air cooled, Water cooled
Max daily production: 145 kg
(referred to the standard model)
  • ECM 226 AS 230/50
Max bin capacity: 70 kg
Dimensions without legs: W 1078 mm D 715 mm H 1004 mm
Dimensions with legs: W 1078 mm D 715 mm H 1082 mm
